DIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting Blow

Brand Name : AMPFORT

Model Number : MTS1500A

Certification : UL VDE CCC CQC PSE KC

Place of Origin : Dongguan,China

MOQ : 5000pcs

Price : 0.03 usd/pc

Payment Terms : T/T

Supply Ability : 10KKPCS PER MONTH

Delivery Time : 7 workdays

Packaging Details : Tape,1k per ammo

Name : Square Time Delay Burn Fuse

Material : Plastic

Lead : Radial

Shape : Round or Square

Package : Taped

Speed : Slow blow

Votlage : 250V

Current : 5A

Contact Now

DIP Mounted Square Time Delay Burn Fuse MTS1500A T5A250V 8x4x7mm UL VDE CCC CQC PSE KC Black Slow Acting Blow SMT

DIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting Blow

This product is suitable for various kinds of electronic devices’ circuit over current protection. Widely used in industrial of Battery Charges, Consumer Electronics, Power supplies, Industrial Controllers, etc.

AMPFORT Micro Fuses Selection Guide
Series Size(mm) Blow Type Voltage Current Range Interrupting Rating
MFC 8x4x5 Fast Acting 250V/300V 0.05~25A 35A@250V/300V
MTC 8x4x5 Slow Blow 250V/300V 0.05~25A 35A@250V/300V
MFS 8x4x7.7 Fast Acting 250V 0.05~20A 35~50A@250V
MTS 8x4x7.7 Slow Blow 250V 0.05~20A 35~50A@250V
NFS 8x4x7.7 Fact Acting 300V 0.05~20A 35~50A@300V
NTS 8x4x7.7 Slow Blow 300V 0.05~20A 35~50A@300V
FMS 8x4x7.7 Facst Acting 350V/400V/500V 0.05~20A 35~50A@300V/400V/500V
TMS 8x4x7.7 Slow Blow 350V/400V/500V 0.05~20A 35~50A@300V/400V/500V
96F 12x6x9 Fast Acting 125V/250V/300V/350V/500V 0.05~20A

100A@500V

400A@125V/250V

100A@300V/350V
96T 12x6x9 Slow Blow 125V/250V/300V/350V/500V 0.05~20A

100A@500V

400A@125V/250V

100A@300V/350V

DIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting Blow

DIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting Blow

Application

Flat–panel Display TV Industrial equipment
LCD monitor Power Adaptor
Lighting system Audio/Video System
Medical equipment LCD Backlight inverter

DIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting Blow

Catalog

No.

Ampere

Rating

Voltage

Rating

Max Voltage

Drop (mv)

I2TMelting

Integral(A2.S)
MTS0050A 50mA 250V 1600 0.015
MTS0063A 63mA 250V 1600 0.016
MTS0080A 80mA 250V 1500 0.017
MTS0100A 100mA 250V 1500 0.02
MTS0125A 125mA 250V 760 0.10
MTS0160A 160mA 250V 500 0.15
MTS0200A 200mA 250V 260 0.21
MTS0250A 250mA 250V 240 0.48
MTS0315A 315mA 250V 220 0.78
MTS0400A 400mA 250V 200 1.22
MTS0500A 500mA 250V 190 2.11
MTS0630A 630mA 250V 180 2.88
MTS0800A 800mA 250V 160 3.92
MTS1100A 1A 250V 140 5.77
MTS1125A 1.25A 250V 130 8.34
MTS1160A 1.6A 250V 120 13.60
MTS1200A 2A 250V 100 26
MTS1250A 2.5A 250V 100 42
MTS1300A 3A 250V 100 45
MTS1315A 3.15A 250V 100 90
MTS1350A 3.5A 250V 100 100
MTS1400A 4A 250V 100 120
MTS1500A 5A 250V 100 170
MTS1630A 6.3A 250V 100 290
MTS1800A 8A 250V 100 320
MTS2100A 10A 250V 95 450
MTS2100A 12A 250V 95 460
MTS2100A 15A 250V 85 480
MTS2100A 16A 250V 85 515
MTS2100A 20A 250V 85 960

Materials Details

NO. Part Name Mateiral
1 Cap Black or Brown Thermoplastic Polyamide PA 6.6, UL 94 V-0
2 Base Black or Brown Thermoplastic Polyamide PA 6.6, UL 94 V-0
3 Fuse element Alloy

Operating Characteristics

% of Ampere Rating(In)

Blowing Time
150%* In 60 min Minimum
210%* In 2 min Max
275%* In 400 ms~10 s
400%* In 150 ms~3 s
1000%* In 20 ms~150 ms

DIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting BlowDIP Mounted Square Time Delay Burn Fuse T5A250V 8x4x7mm UL VDE PSE KC Black Slow Acting Blow
