B57703M0103A019 Cross Ring Lug Eyelet Temperature Sensors NTC 10KOHM 3988K Free Hanging Probe Assemblies

Name: B57703M0103A019 Cross Ring Lug Eyelet Temperature Sensors NTC 10KOHM 3988K Free Hanging Probe Assemblies
Brand: CNAMPFORT
Price: 1 USD

Best B57703M0103A019 Cross Ring Lug Eyelet Temperature Sensors NTC 10KOHM 3988K Free Hanging Probe Assemblies wholesale

Brand Name : CNAMPFORT

Model Number : CWF103G3988FM500RW

Certification : ROHS

Place of Origin : Dongguan,China

MOQ : 1000

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 10KKPCS Per Month

Delivery Time : 7-10 workdays

Packaging Details : Bulk

Name : Eyelet Temperature Sensors

Package / Case : Ring Lug

Mounting Type : Free Hanging

Length - Lead Wire : 19.68" (500mm)

Operating Temperature : -55°C ~ 125°C

B25/100 : 3988K

B Value Tolerance : ±1%

Resistance in Ohms @ 25°C : 10k

Resistance Tolerance : ±2%

HTSUS : 8533.40.8070

Contact Now

B57703M0103A019 Cross Ring Lug Eyelet Temperature Sensors NTC 10KOHM 3988K Free Hanging Probe Assemblies

B57703A0103A019 Cross CWF103G3988FM500RW is Probe assemblies, NTC thermistors for temperature measurement.Desined for Surface temperature measurement, e.g. on housings and heat sinks.

1. High accuracy

2. Easy mounting

3. Good thermal coupling through metal tag Thermistor encapsulated in metal-tag case

4. AWG 30, PTFE-insulated leads of silver-plated nickel wire or AWG 26 (stranded, 7 x AWG 34), PTFE-insulated leads of silver-plated copper wire

5. Options

Alternative resistance ratings, rated temperatures, resistance tolerances, lead lengths and AWG 28 stranded wires available on request.

6.Delivery mode Bulk

Electric tool,copier,fax machine,printer,BMS CAR BATTERY ,Power inverter,New energy electric vehicle power battery,Electric kettle,Electric oven,Refrigerator,oil press,electric blanket,Hot water bag/Warm handbag/Fascia gun,UPS Power,energy storage etc.

1. Overview

B57703M0103A019 Cross Ring Lug Eyelet Temperature Sensors NTC 10KOHM 3988K Free Hanging Probe Assemblies

Product Name	Manufacturer Clip Pipe Temperature Sensor NTC High Temperature Water Temp Probe
NTC Thermistor	R25=10KΩ±2%
B value	B25/100=3988K±1%
Housing	Φ3.7*17 metal tag
Wire length	UL1332#26AWG TS BLACK 500+/-10mm
End	Tinned
Working temp.	-55~125C, can be customize as per customer's request
Application	Air Conditioner, coffee machine, oven etc.

Tell us your requirements

* The application of the NTC thermistor:__________

* Working environment of NTC thermistor:________

* Operation temperature range:___ºC to ___ºC

* Any requirement about sensor probe material or dimension:______________

* The R value:___K ohm ±___% at ___ºC,

* The B value: B(____ºC/____ºC) = _____K ± ___%

B57703M0103A019 Cross Ring Lug Eyelet Temperature Sensors NTC 10KOHM 3988K Free Hanging Probe Assemblies
